Product Introduction
Feature & Application:
Ø Effectively suppress the electromagnetic interference on line to line and line to ground
Ø Highly efficient and cost-effective
Ø Suitable for switching power supply, UPS, vending machines, embroidery machines, oscilloscopes, industrial computers, controllers and many other devices
Technical Data:
Rated voltage
110/250VAC
Rated current
1A～250A
Operating frequency
50/60Hz
Temperature Range
HPF25/085/21
Test voltage(1min)
Line to Line 1760VDC
Line to Ground 2000VAC
Electrical schematics:
Selection Table:
|
EMI Filter |
Rated Current(A) |
Rated Voltage (V) |
Leakage Current (mA) |
Electrical Schematic |
Input/output Connections |
|
EFA101-1-W |
1 |
110/250 |
0.5 |
Fig.1 |
Wire |
|
EFA101-3-W |
3 |
110/250 |
0.5 |
Fig.1 |
Wire |
|
EFA101-6-W |
6 |
110/250 |
0.5 |
Fig.1 |
Wire |
|
EFA101-10-F |
10 |
110/250 |
0.5 |
Fig.1 |
Faston |
|
EFA102-6-F |
6 |
110/250 |
1.0 |
Fig.2 |
Faston |
|
EFA102-10-F |
10 |
110/250 |
1.0 |
Fig.2 |
Faston |
|
EFA102-20-F |
20 |
110/250 |
1.0 |
Fig.2 |
Faston |
|
EFA102-6-M |
6 |
110/250 |
1.0 |
Fig.2 |
Screw |
|
EFA102-10-M |
10 |
110/250 |
1.0 |
Fig.2 |
Screw |
|
EFA102-20-M |
20 |
110/250 |
1.0 |
Fig.2 |
Screw |
|
EFA102-30-M |
30 |
110/250 |
1.0 |
Fig.2 |
Screw |
|
EFA102-50-M |
50 |
110/250 |
2.0 |
Fig.2 |
Screw |
|
EFA102-100-M |
100 |
110/250 |
2.0 |
Fig.2 |
Screw |
|
EFA102-150-M |
150 |
110/250 |
2.0 |
Fig.2 |
Screw |
|
EFA102-200-M |
200 |
110/250 |
2.0 |
Fig.2 |
Screw |
