Product Introduction
Feature & Application:
Ø Specially designed for IEC standard connector
Ø One or two fuses can be installed
Ø Safe and reliable, easy to install and cost-effective
Ø Medical appliances optional
Technical Data:
|
Rated voltage |
110/250VAC |
|
Rated current |
1A～10A |
|
Operating frequency |
50/60Hz |
|
Temperature Range |
HPF25/085/21 |
|
Test voltage(1min) |
Line to Line 1500VDC |
|
Line to Ground 1500VAC |
Electrical schematics:
Selection Table:
|
EMI Filter |
Rated Current(A) |
Rated Voltage (V) |
Leakage Current (mA) |
Electrical Schematic |
Input/output Connections |
|
EFAS103-1-A |
1 |
110/250 |
0.5 |
Fig.1 |
Faston |
|
EFAS103-3-A |
3 |
110/250 |
0.5 |
Fig.1 |
Faston |
|
EFAS103-6-A |
6 |
110/250 |
0.5 |
Fig.1 |
Faston |
|
EFAS103-10-A |
10 |
110/250 |
0.5 |
Fig.1 |
Faston |
|
EFAS103-1-C |
1 |
110/250 |
0.5 |
Fig.2 |
Faston |
|
EFAS103-3-C |
3 |
110/250 |
0.5 |
Fig.2 |
Faston |
|
EFAS103-6-C |
6 |
110/250 |
0.5 |
Fig.2 |
Faston |
|
EFAS103-10-C |
10 |
110/250 |
0.5 |
Fig.2 |
Faston |
