Product Introduction
Feature & Application:
Ø Specially designed based on the frequency-domain characterization of interference generated by inverter output to load
Ø Effectively reduce the interference generated by inverter output
Ø Various connection ways, protective covers and terminal block terminals optional
Ø Specially designed based on the frequency-domain characterization of interference generated by inverter input towards electric network and other digital equipments
Ø Good performance of suppressing common mode and differential mode interference, effectively suppress the conduced interference from inverter
Ø Various connection ways, protective covers and terminal block terminals optional
Ø Suitable for working place with strict requirement of environment
Technical Data:
|
Rated voltage |
250/440/480VAC |
|
Rated current |
6A～1200A |
|
Operating frequency |
50/60Hz |
|
Temperature Range |
HPF25/085/21 |
|
Test voltage(1min) |
Line to Line 2250VDC |
|
Line to Ground 2700VDC |
Electrical schematics：
Selection Table:
|
EMI Filter |
Rated Current(A) |
Rated Voltage (V) |
Leakage Current (mA) |
Input/output Connections |
|
EFC301-6-M |
6 |
250/440/480 |
7.5 |
Screw |
|
EFC301-10-M |
10 |
250/440/480 |
7.5 |
Screw |
|
EFC301-15-M |
15 |
250/440/480 |
7.5 |
Screw |
|
EFC301-20-M |
20 |
250/440/480 |
7.5 |
Screw |
|
EFC301-25-M |
25 |
250/440/480 |
7.5 |
Screw |
|
EFC301-30-M |
30 |
250/440/480 |
7.5 |
Screw |
|
EFC301-40-M |
40 |
250/440/480 |
13.0 |
Screw |
|
EFC301-50-M |
50 |
250/440/480 |
13.0 |
Screw |
|
EFC301-60-M |
60 |
250/440/480 |
13.0 |
Screw |
|
EFC301-80-M |
80 |
250/440/480 |
40.0 |
Screw |
|
EFC301-100-M |
100 |
250/440/480 |
40.0 |
Screw |
|
EFC301-120-M |
120 |
250/440/480 |
40.0 |
Screw |
|
EFC301-150-M |
150 |
250/440/480 |
50.0 |
Screw |
|
EFC301-200-M |
200 |
250/440/480 |
50.0 |
Screw |
|
EFC301-300-B |
300 |
250/440/480 |
45.0 |
Busbar |
|
EFC301-400- B |
400 |
250/440/480 |
45.0 |
Busbar |
|
EFC301-500- B |
500 |
250/440/480 |
60.0 |
Busbar |
|
EFC301-630- B |
630 |
250/440/480 |
60.0 |
Busbar |
|
EFC301-800- B |
800 |
250/440/480 |
90.0 |
Busbar |
|
EFC301-1000-B |
1000 |
250/440/480 |
90.0 |
Busbar |
